Sale!

RS485 MODBUS LED Flush Diaphragm Pressure Transducer 60Mpa Hydraulic Oil Pressure Sensor Pressure Transmitter Online Sale

Original price was: $105.40.Current price is: $26.35.

SKU: US-7362145714369 Categories: , Tag:

Description

RS485 MODBUS LED Flush Diaphragm Pressure Transducer 60Mpa Hydraulic Oil Pressure Sensor Pressure Transmitter

SPECIFICATIONS

RS485 MODBUS LED Flush Diaphragm Pressure Transducer 60Mpa Hydraulic Oil Pressure Sensor Pressure Transmitter

Sensor: Diffusion silicon chip

Product name: Pressure transmitter

Power supply: DC24V

Output signal: RS485

Origin: Mainland China

Model Number: ELPT400

Measure range: -0.1~0~100MPa

Max Measuring Range: 400 Bar & Above

Material: Stainless Steel

Connection thread: M20*1.5

Certification: CE,FCC,RoHS

Brand Name: KEJUN

Accuracy: 0.2%FS

RS485 MODBUS LED Flush Diaphragm Pressure Transducer 60Mpa Hydraulic Oil Pressure Sensor Pressure Transmitter

This link is special for:
1. Measuring range: the one you choose
2. Output signal: RS485
3. Power supply: DC24V
4. Connection thread: M20*1.5

Notes:

What we can make:

1. Available measuring range: any range within -0.1Mpa~0~100Mpa (-1bar~0~1000bar).

2. Available output signal: 4~20mA, 0-10V, 0-5V, 0.5~4.5V, RS485.

3. Available power supply: 12~30Vdc, 24Vdc, 12Vdc

4. Available thread: M20*1.5, G1/2, G1/4, NPT1/2, NPT1/4, etc

So: if you need other parameters, please contact me.

And tell me the measuring range, output signal, power supply, thread size.

We can make special customization for you.

PRODUCT DATA SHEET DOWNLOAD

Additional information

Measuring Range

-0.1 to 1Mpa, 0-0.1Mpa, 0-0.16Mpa, 0-0.25Mpa, 0-0.4Mpa, 0-0.6Mpa, 0-1Mpa, 0-1.6Mpa, 0-2.5Mpa, 0-4Mpa, 0-6Mpa, 0-10Mpa, 0-16Mpa, 0-20Mpa, 0-25Mpa, 0-30Mpa, 0-40Mpa, 0-50Mpa, 0-60Mpa, Customization
