AC 0-100A 3 Phase Current Transducer 3 wire Analog Output 4-20ma 0-10v Three Phase AC Current Transducer Online Hot Sale

Original price was: $93.02.Current price is: $27.91.

SKU: US-7362138341569 Categories: , Tag:

Description

AC 0-100A 3 Phase Current Transducer 3 wire Analog Output 4-20ma 0-10v Three Phase AC Current Transducer

SPECIFICATIONS

AC 0-100A 3 Phase Current Transducer 3 wire Analog Output 4-20ma 0-10v Three Phase AC Current Transducer

Supply Voltage: DC12V-24V

Response time: <200ms

Product name: 3 phase current transducer

Output signal: 4-20mA,0-5V,0-10V,1-5V

Origin: Mainland China

Operating Temperature: -30℃~+85℃

Model Number: ELCT-3P2

Installation method: DIN 35mm rail+ plane screw fixation

Input current range: AC 0-400A

Frequency range: 40-60HZ

Display Type: Analog Only

Dimensions: 10mm,20mm

DIY Supplies: ELECTRICAL

Certification: CE

Brand Name: KEJUN

Accuracy Class: 0.5%FS

AC 0-100A 3 Phase Current Transducer 3 wire Analog Output 4-20ma 0-10v Three Phase AC Current Transducer

DATA SHEET DOWNLOAD

NOTES:

The 3 phase current transducer can make any range within AC0~400A.

If you need other current range, please contact me.

We can make special customization for you.


Product Description

1>>. Working principle: Open loop direct measurement.

2>>. Usage: Used for measuring 3 phase AC current.

3>>. Advantages: Better cost-performance,low power consumption,small volume,light weight,easy installation,perforation input and no insertion loss.

4>>. Application: Frequency conversion speed control system,electric welding machine,electro-chemistry,power supply monitoring,electric locomotive,low level starting protection.

5>>. The input,output,power and outer shell are isolated,with strong anti-interference ability and high reliability.

6>>. Full channel configuration,parameters customized.

Additional information

Color

4-20mA output, 0-5Vdc output, 0-10Vdc output, 1-5Vdc output
Measuring Range

3xAC 0-5A, 3xAC 0-10A, 3xAC 0-50A, 3xAC 0-80A, 3xAC 0-100A, 3xAC 0-150A, 3xAC 0-200A, 3xAC 0-250A, 3xAC 0-300A, 3xAC 0-350A, 3xAC 0-400A, Customization
