90W DC Gear Motor 12V 24V High Torque 200KG Reducer Speed 10rpm -600rpm Permanent Magnet Gearbox Motor Long Life Low Noise 12 V Discount

Original price was: $246.50.Current price is: $61.62.

SKU: US-10129923080385 Categories: , Tag:

Description

90W DC Gear Motor 12V 24V High Torque 200KG Reducer Speed 10rpm -600rpm Permanent Magnet Gearbox Motor Long Life Low Noise 12 V

SPECIFICATIONS

90W DC Gear Motor 12V 24V High Torque 200KG Reducer Speed 10rpm -600rpm Permanent Magnet Gearbox Motor Long Life Low Noise 12 V

Brand Name: HYSMOTOR

Certification: CCC

Certification: ROHS

Origin: Mainland China

Continuous Current(A): 8A

Output Power: 90W

Commutation: Brush

Type: Gear Motor

Protect Feature: Drip-proof

Construction: Permanent Magnet

Usage: BoAt

Usage: car

Usage: Electric Bicycle

Usage: Fan

Usage: Home Appliance

Efficiency: IE 1

Model Number: 90W

Torque: 200kG.cm

Application

The following is the picture of the motor

Friendly reminder

Recently, this motor is in the upgrade stage. There are some changes in the shape and color of the motor after the upgrade. However, the size and performance of the motor are unchanged.

Our warehouse will randomly send the motor, you may receive the motor before the upgrade, you may also receive the upgraded motor, please know before buying, thank you.

The size is for reference only,the measurement will be slightly different,please pay attention before buying

The following is a description of the quality materials and structures of this motor.

1. Using imported lubricating oil, it can reduce the friction of the motor, control the speed of the motor temperature rise, reduce the running noise and extend the life of the motor.

2. The wire in the rotor is made of pure copper. It is more conductive,resistant to temperature and prolongs the life of the motor.

3. Use all metal gears inside the gearbox

The parameter table of the motor

Introduction of the motor

1. Name of the motor: XD5D90-12GN-18S DC Gear Motor 12V 24V In DC Motor

2. Rated voltage have DC 12V and DC 24V

3. DC 12V ; You can choose the no load speed have : 10rpm/20rpm/30rpm/50rpm/100rpm/200rpm/300rpm/400rpm/600rpm

Rated torque between 6.53 To 200 KGF.CM; Select a no load speed in DC 12V, there will be corresponding rated torque , please refer to the parameter table below.

4. DC 24V ; You can choose the no load speed have :
10rpm/20rpm/30rpm/50rpm/100rpm/200rpm/300rpm/400rpm/600rpm

Rated torque between 6.53 To 200 KG.CM; Select a no load speed in DC 24V, there will be corresponding rated torque , please refer to the parameter table below.

5. Power : 90W

6. Direction of rotation of the motor: CW Or CCW, Support Reversed;
Control the clockwise or counterclockwise rotation of the motor by changing the way the positive and negative electrodes are connected

7. Gear material: Metal gears make the motor last longer

8. The speed of the motor can be adjusted using the speed controller.

9. Low Noise 35dB

10. Continuous operation for 24 hours

11. Outstanding features: low energy consumption; high efficiency; stable operation

12. This motor is suitable for a variety of micro-automation equipment. As long as you confirm that the motor voltage and torque of your choice are suitable for the voltage and load of your project before purchase, there is no limit to the scope of use of this motor.

For example, Office automation; home automation; production automation; medical equipment; security equipment; consumer electronics; automotive electronics; automatic money counters; vending machines; video recorders etc.

Additional information

Speed(RPM)

12v 10rpm 200kgf.cm, 12v 20rpm 200kgf.cm, 12v 30rpm 156kgf.cm, 12v 50rpm 105kgf.cm, 12v 100rpm 52kgf.cm, 12v 200rpm 29kgf.cm, 12v 300rpm 19kgf.cm, 12v 400rpm 16kgf.cm, 12v 600rpm 10kgf.cm, 24v 10rpm 200kgf.cm, 24v 20rpm 200kgf.cm, 24v 30rpm 156kgf.cm, 24v 50rpm 105kgf.cm, 24v 100rpm 52kgf.cm, 24v 200rpm 29kgf.cm, 24v 300rpm 19kgf.cm, 24v 400rpm 16kgf.cm, 24v 600rpm 10kgf.cm
